Impedance products
Zurich Instruments offers powerful tools for all types of impedance measurements. Whether you need a high-accuracy impedance analyzer, or a high-speed multi-frequency impedance spectroscope, we have the right instrument for you.
The MFIA is a digital impedance analyzer and precision LCR meter that sets the new standard for impedance measurements in the frequency range from 1 mHz to 5 MHz. The MFIA provides 0.05% basic accuracy and a measurement range spanning from 1 mΩ to 1 TΩ. The instrument has a high measurement repeatability and a small temperature drift. With the LabOne® user interface the MFIA offers a number of long-awaited innovations for the impedance and LCR measurement available without the need of any software installation.
Go to the product page and get in touch to discuss your application.
Go to the MFIA Product Video
Application notes
Related blog post
- Using the MFIA Impedance Analyzer to characterize the ESR of a Super-capacitor
- The Nyquist Diagram for Electrical Circuits
- Characterizing High-Q 100 pF Capacitors with the Zurich Instruments MFIA
- Time-Domain Response of Lock-in Filters
- Teraohm Impedance measurements with the MFIA Impedance Analyzer
HF2IS
50 MHz Impedance Spectroscope
The HF2IS provides dynamic and static impedance spectroscopy where the speed of the measurement is a priority. Two differential measurement units with a wide frequency range and 4 dual-phase demodulators are matched with the unprecedented precision of a 128-bit DSP engine. This allows multi-frequency measurements with very high sensitivity to relative changes in impedance parameters. The HF2IS satisfies the highest impedance spectroscopy measurement requirements of leading research laboratories.
Go to the product page and get in touch to discuss your application.
Related blog posts
- Permittivity Measurement with HF2IS Impedance Spectroscope
- Characterization of Dye-Sensitized Solar Cell Impedance at Low Frequencies with HF2IS Impedance Spectroscope
- Deep Level Transient Spectroscopy Using HF2LI Lock-in Amplifier
- Using HF2IS Impedance Spectroscope as a DC Impedance Meter
- Detecting a small fraction of impedance changes with improved sensitivity
- Taking Your Microfluidics EIS Measurement to the Ultra-High Frequency Domain
- Express EIS Platform for Microfluidics
